| TECHNICAL SPECIFICATIONS | ||||
|---|---|---|---|---|
| Size | 16mm to 90mm & ½" to 3½” | |||
| Standard | BS 6121 : Part-1:2005, EN 50262:1999 | |||
| Function | For indoor & outdoor use with all types of SWA cable providing environmental seal on both the cable inner & outer sheaths. Also provides mechanical retention & electrical continuity via armour wire termination. | |||
| Ingress Protection | IP66 | |||
| Material | Brass BS 2874 | |||
| Thread | Metric, BSC (ET) | |||
| Operating Temp | -20°C to +80°C | |||
| Cable Type | Steel Wire (SWA) Cable | |||
| Features | Displacement seal and Universal anyway clamping ring | |||
| Accessories | Shroud, Earth Tag, Serrated washer. Lock nut and Entry Thread Seal. | |||
