Brass cap nut is a type of fastener which gets its name from its shape. It is a nut that has a domed top to prevent contact with the external thread. Applications with high water temperatures, chlorides present or deviating water qualities (soft water) play a role.
| TECHNICAL SPECIFICATIONS | ||
|---|---|---|
| Material | Brass | |
| Thread | Coarse | |
| Size | Cap Nut | |
| Size | 1/4" | |
| Grade | Free Cutting Brass, CDA 360 Brass, C360 Brass | |
| Brass Cap Nuts |
• BS 3692 • BS 57 • IS/1363 • IS/1367 |
|
| Nut Sizes | Flats | Height |
|---|---|---|
| #4-40 | 1/4" | 1/4" |
| #6-32 | 5/16" | 9/32" |
| #8-32 | 5/16" | 9/32" |
| #10-24 | 3/8" | 11/32" |
| #10-32 | 3/8" | 11/32" |
| #12-24 | 3/8" | 11/32" |
| 1/4"-20 | 7/16" | 3/8" |
| 1/4"-28 | 7/16" | 3/8" |
| 5/16"-18 | 9/16" | 7/16" |
| 5/16"-24 | 9/16" | 7/16" |
| 3/8"-16 | 5/8" | 1/2" |
| 3/8"-24 | 5/8" | 1/2" |
| 7/16"-14 | 3/4" | 9/16" |
| 7/16"-20 | 3/4" | 9/16" |
| 1/2"-13 | 3/4" | 9/16" |
| 1/2"-20 | 3/4" | 9/16" |
| 5/8"-11 | 1" | 3/4" |
| 5/8"-18 | 1" | 3/4" |
| 3/4"-10 | 1-1/16" | 7/8" |
